HFM-CL Complete Automatic Hot Filling Production Line Bottle Feeding Filling Capping Labeling Integrated

Gambar besar : HFM-CL Complete Automatic Hot Filling Production Line Bottle Feeding Filling Capping Labeling Integrated

Detail produk:

Tempat asal:	Shanghai, Tiongkok
Nama merek:	Gieni
Sertifikasi:	CE, ISO 9001, GMP
Nomor model:	HFM-CL

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	USD 35000-60000 / Set
Kemasan rincian:	Pengemasan ekspor multi-peti dengan kit alat instalasi dan dukungan commissioning di lokasi
Waktu pengiriman:	50-70 hari kerja
Syarat-syarat pembayaran:	T/T, L/C
Menyediakan kemampuan:	8 Set per bulan

Kontak

HFM-CL Complete Automatic Hot Filling Production Line Bottle Feeding Filling Capping Labeling Integrated

Deskripsi

Konfigurasi Garis:	Pemberian Botol + Pengisian Panas + Pembatasan + Pelabelan	Mengisi Nozel:	8-12 (Dapat Dikonfigurasi)
Kapasitas Tangki:	60L (Dapat Diperluas)	Kecepatan Produksi:	40-60 botol/menit
Sistem Pengendalian:	PLC Pusat dengan HMI Multi-Stasiun	Metode pemanasan:	Pemanasan Jaket Listrik
Bahan tubuh:	Baja Tahan Karat 304	bahan kontak:	Baja Tahan Karat 316L
Kekuatan:	Jumlahnya 20 KW	Voltase:	380V 3-fase
Panjang garis:	Dapat disesuaikan
Menyoroti:	Complete Filling Production Line , Bottle-to-Label Integration , Fully Automatic Turnkey Solution

HFM-CL Complete Automatic Hot Filling Production Line

The HFM-CL is a fully integrated turnkey hot filling production line that combines automatic bottle feeding, precision hot filling, capping, and labeling into one seamless system. Controlled by a central PLC with multi-station HMI panels, it delivers a complete production solution from empty bottle to labeled finished product.

Key Features

Complete Turnkey Solution: Single-source responsibility for the entire line — bottle unscrambler, conveyor, hot filler, capper, and labeler — all pre-tested as one system before shipment.
Central PLC Control: Unified control architecture with synchronized line speed, automatic accumulation control, and single-point recipe management across all modules.
Flexible Configuration: Choose 8 or 12 filling nozzles and 60L standard or expanded tank capacity based on production requirements.
Quick Installation: Modular design with pre-wired connections and alignment pins enables installation and commissioning within 3-5 days.
On-Site Support: Includes remote and optional on-site commissioning by Gieni engineers for guaranteed production ramp-up.

Technical Specifications

Parameter	Specification
Model	HFM-CL
Output	40-60 bottles/min
Total Power	20 KW
Line Length	Customizable
