VS016-S Semi-Automatic Lipstick Filling Production Line 20-30 pcs/min Cost-Effective Entry Level

Name: VS016-S Semi-Automatic Lipstick Filling Production Line 20-30 pcs/min Cost-Effective Entry Level
Brand: Shanghai Gieni Industry Co.,Ltd
SKU: VS016-S
Price: 16,000.00 USD
Availability: InStock

Semua produk

Mesin mengisi kosmetik
(115)

Mesin Pengisi Mascara
(68)

Mesin Pengisi Lip Gloss
(48)

Mesin Pengisian Panas
(49)

Mesin Pengisi Lipstik
(85)

Mesin Press Serbuk Kosmetik
(81)

Mesin Pelabelan Kosmetik
(20)

Mesin Filling Polish Cat
(21)

Mesin Pengisi Minyak Esensial
(9)

Mesin Pengisi Vaselin
(10)

Mesin Pembuat Cat Kuku
(8)

Mesin Pengisi Toner
(8)

Mesin Pengisi Balsem Bibir
(10)

Mesin Pengisi Kosmetik Berwarna
(24)

Mesin pengisi bantal
(18)

Produk terbaik

Mesin cetak lipstik silikon canggih untuk mengisi lipstik massal

Sertifikasi

I 'm Online Chat Now

VS016-S Semi-Automatic Lipstick Filling Production Line 20-30 pcs/min Cost-Effective Entry Level

Gambar besar : VS016-S Semi-Automatic Lipstick Filling Production Line 20-30 pcs/min Cost-Effective Entry Level

Detail produk:

Tempat asal:	Shanghai, Tiongkok
Nama merek:	Gieni
Sertifikasi:	CE, ISO 9001
Nomor model:	VS016-S

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	USD 12000-20000 / Set
Kemasan rincian:	Peti kayu kelas ekspor dengan bantalan busa
Waktu pengiriman:	20-30 hari kerja
Syarat-syarat pembayaran:	T/T, L/C, Western Union
Menyediakan kemampuan:	30 set per Bulan

Kontak

VS016-S Semi-Automatic Lipstick Filling Production Line 20-30 pcs/min Cost-Effective Entry Level

Deskripsi

Tipe Mesin:	Lini Produksi Lipstik Semi-Otomatis	Sistem Pengendalian:	PLC dengan layar sentuh HMI
Kecepatan Produksi:	20-30 buah/menit (1200-1800 buah/jam)	Tingkat otomatisasi:	Semi-Otomatis (Pemuatan Manual + Pemrosesan Otomatis)
Voltase:	3P 380V / 1P 220V	Kekuatan:	8 kW
Tekanan udara:	0,5-0,8 MPa	Bahan tubuh:	Baja Tahan Karat 304
bahan kontak:	Baja Tahan Karat 316L	Fungsi:	Pengisian Otomatis, Peleburan Terbalik, Pembekuan, Pembatasan, Pengepresan
Bahasa:	Cina / Inggris
Menyoroti:	Cost-Effective Entry Solution , Semi-Automatic Filling System , 20-30 pcs/min Output

VS016-S Semi-Automatic Lipstick Production Line

The VS016-S is an affordable entry-level semi-automatic lipstick production line, purpose-built for startups, small-batch manufacturers, and R&D labs. It retains the core automatic processes — filling, reverse melting, freezing, capping, and pressing — while using manual tube loading to reduce initial investment cost.

Key Features

Cost-Effective Investment: Significantly lower capital investment compared to fully automatic lines while maintaining the same 304/316L stainless steel build quality.
20-30 pcs/min Output: Ideal production speed for small to medium batch sizes (1,200-1,800 pcs/hour), suitable for niche brands and contract manufacturers.
PLC Touch Screen Control: Same advanced HMI as the fully automatic VS016 series, with recipe management and multi-language support.
Automatic Core Processes: Filling, reverse melting, freezing, capping, and pressing are fully automated, ensuring product consistency.
Manual Tube Loading: Simple manual hopper loading reduces system complexity, maintenance costs, and operator training requirements.
Upgrade Path: Modular design allows future upgrade to fully automatic tube feeding as production volume grows.

Technical Specifications

Parameter	Specification
Model	VS016-S
Speed	20-30 pcs/min
Output	1200-1800 pcs/hour
Power	8 KW
Voltage	3P 380V / 1P 220V
Air Pressure	0.5-0.8 MPa
